Industrial all-in-one-industrial touch screen pc_industrial computer-industrial touch screen pc-Industrial embedded computer-androidindustrial computer-industrial display screen-industrial pc manufacturers

SyoungUltra-thin industrial all in one PCIndustrial grade quality7MM front fr<x>ameResponsible for appearance7mm slim designIP65 RatingAlu alloy enclosure24hrs/7days UsageVbration proof

Specification		Parameter
Screen	size	15.6¨ 、18.5¨ 、21.5¨
	Resolution	1920×1080
	screen brightnes	300cd/m²
Capacitive touch	Surface hardness	6H
Capacitive touch	Number of contacts	10 point
Trumpet	Built-in empty	2W+2W/8Ω；
Hardware	CPU	Intel Celeron J1900 quad core 2.0GHz
	chipset	Intel Bay trail SOC
	GPU	Intel HD Graphics(Sandy Bridge)
	ROM	2GB DDR3
	RAM	64G SSD
IO	LAN	1-way RJ45 network port support wake on LAN and PXE diskless boot function. WiFi
	Audio	Support audio output (green) Support microphone input (red)
	USB	USB 3.01 USB2.03
	RS232	RS232*2
	Display interface	DB15 VGA HDMI
	Button	M12 metal switch button
Other	working environment	Working temperature: -10~60℃; Working humidity: 5%~95% relative temperature no condensation
	storage environment	Storage temperature: -20~60℃; Storage humidity: 5%~95% relative temperature no condensation
	Power on	BIOS supports power-on timed-on and remote power-on/off settings
	electronic dog	Support watchdog hardware reset function (256 levels 0~255 seconds)
	Size	As shown below
	Protection class	Surface IP65
	Power supply	DC12V（±10%）
	Installation method	wall-mounted desktop
Packing List	Machine1 Power Adapter1 Power Cord1 Instruction Manual1 Certificate*1
